Hot Runner Nozzle Coil Heater With Thermocouple

Hot Runner Nozzle Coil Heater With Thermocouple

hot runner nozzle coil heater with thermocouple’s production length in 200-3000mm is mainly used for hot runner mold or, as well as other precision heating system. Spring heating ring external using high quality Ni-Cr steel tube, the internal use of high purity magnesium oxide , high temperature...

Description

hot runner nozzle coil heater with thermocouple’s production length in 200-3000mm is mainly used for hot runner mold or, as well as other precision heating system. Spring heating ring external using high quality Ni-Cr steel tube, the internal use of high purity magnesium oxide , high temperature resistance wire, and first-class manufacturing technology . The wire is after the annealed, with flexibility can be bent into an arc or circle heating. Its high working temperature, fast heating, uniform heating precision, long service life, can be automatically controlled area, high thermal conduction, while internal heating material damage, external can reus

Name of product
hot runner nozzle coil heater with thermocouple
Inner Diameter of coiled heater
8-38mm( + 0.05mm)
Coil style Length
40-200mm (+ 0.5mm)
staright style length
200-3000mm (+ 0.5mm)
Cross-section
Round:Dia.3mm;3.3mm;3.5mm
Square: 3x3mm;3.3x3.3mm,4x4mm,
Rectangular:4.2x2.2mm,4x2mm;1.3x2.2mm
Tube Material
SUS304/SUS/310S/Incoloy800
Tube color
sliver or annealed black
Insulation
High pure Mgo
Inner heating element
NiCr8020
Voltage
12v;24v;110v;220v;240v;380v
Wattage
200-3000w( 6.5W/CM2 ) + 5% tolerance
Max. Temperature:
650°C
Built-in thermocouple
with or without J /K TC(Available)
Delivery Time
3-5 days(10-500pcs)
7 days(more than 500pcs)

Hot Runner heater application:

1. Injection moulding machine nozzle
2. Hot Runner Nozzles & Bushings.
3. Packaging machineries
4. Hot runner Injection moulds.
5. Injection & Blow Moulding Machine Nozzles.
6. PET prefrom & Thin wall container Moulds
7. Hot runner Manifolds.
