PCB board splitter preparation and usage

In the actual use process, whether it is the use of those PCB splitters, or those automatic splitters, or FPC pulse welding machines, there are many different performances and advantages. The following editor introduces the preparations for the use of PCB splitters and the use of the situation, welcome to read!

Preparations before using the PCB splitter:

Before using the PCB splitter, please read this manual in detail, it will enable your machine to operate safely and smoothly. This machine is only designed to separate circuit boards that have been V-CUT, please do not use it for other purposes. In any case, do not remove the protective plate around the blade to avoid danger. During operation, you should not wear too loose clothes, and long hair should be tied up to avoid being caught by the machine. The height of the upper blade can be adjusted by the upper blade height adjustment knob according to the thickness of the circuit board. Confirm that the parts on the circuit board will not collide with the machine body and the blade. The relevant dimensions on the machine are shown in the figure. The height of the parts on the circuit board should not exceed the range shown in the figure. If the parts on the circuit board touch the blade, you can contact our company to make special processing on the blade to avoid cutting the parts.

Before using the PCB splitter, check the items in the packaging box, including the following parts: main unit, manual, power cord, and hexagonal wrench for adjustment. After confirming that the power supply voltage is correct, you can turn on the machine. According to the height of the parts on the circuit board, adjust the tray to the appropriate height and tighten it with the hexagonal wrench attached to the machine. To prevent static electricity from damaging the parts on the circuit board, the machine should be reliably grounded. If the ground wire in the power socket is reliable and effective, the PCB splitter is reliably grounded when it is powered on. Remove the machine packaging bag, place the machine on a flat and solid workbench, and wipe off the anti-rust grease on the machine blade.

Situation of PCB splitter in use:

1. In the actual use of the PCB splitter, the cutting speed of the splitter can be effectively adjusted according to different boards. Moreover, in the actual use process, it can also play an excellent role in safety maintenance.

2. In the actual use of the PCB splitter, the circular knife is equipped with a blade guard, and there will be no hand injury during the actual operation process.

3. During the actual use of the PCB splitter, it is equipped with a safety protection sensor. During the actual operation, if there is a foreign object in it, the machine will stop operating.

4. During the actual use of the PCB splitter, the gap between the upper and lower knives can be adjusted according to your own needs, which is easy for us to operate.

5. During the actual use of the PCB splitter, the high-speed steel material used can play an excellent wear-resistant effect during the actual operation, which can effectively extend the service life of the equipment.

6. Replace the manual breaking method or the cutting defects of V-CUT or PUCH, and improve the product yield.

7. Equipped with CCD auxiliary program editing and teaching functions, or read AUTO CAD, G CODE code files, with import and export editing and modification functions, accurately simplifying operation learning.

8. It has the functions of automatic target positioning and recognition of visual images, display and tracking of moving trajectory positions, tool life display and production output statistics.

9. Powerful down-suction filter dust collector and static eliminator, cleanly solve the cutting dust problem.

10. Optional automatic feeding and retracting dual operation channels and automatic tool replacement device functions can be configured.

11. Manual or inline supply of substrates can be configured to solve substrate designs of different shapes.
