Solutions for Insufficient CMRR in Hot Runner Systems

Choosing high CMRR temperature control modules, improving signal line shielding and grounding, putting power isolation in place, and performing routine anti-interference verification are some ways to address inadequate CMRR in hot runner systems. These multifaceted enhancements, which range from system design to on-site maintenance, strengthen anti-interference capabilities and guaranty precise and reliable temperature regulation.



1. Update the Fundamental Solution (Core Control Module)

Choose a temperature controller with a high CMRR: Swap it out for an industrial-grade PID module with a CMRR of at least 80dB. Select a digital temperature controller with a CMRR > 100dB for high-end applications.

The Omega CN7800 series and Eurotherm 2408 are recommended brands since they contain noise reduction algorithms and EMC certification.

Turn on Digital Filtering: To reduce high-frequency noise interference, turn on low-pass filtering (e.g., 1~5Hz) in the temperature control parameters.

Practical Value: By upgrading its temperature controller from CMRR 60dB to 100dB, a car injection molding plant was able to reduce temperature variation from ±12°C to ±1.8°C and increase the product certification rate by 9.3%.



2. Signal Transmission Path Optimization (Key Cabling Measures)

Calculates Operational Points

Use Shielded Twisted Pair Cable: To lessen electromagnetic coupling, thermocouple signal lines need to have a twisted pair plus metal shielding structure.

Single-Point Grounding: To prevent ground loops that cause noise, the shielding layer is only grounded at the temperature controller end.

Stay Away from High-Voltage Cables: Keep a minimum of 30 cm between signal lines and motor or heater power cables; cross perpendicularly.

lower Cable Length: To lessen "antenna effect" noise capture, lower the length of the signal cable.

It is advised to connect an oscilloscope in parallel to the thermocouple input for on-site testing. Shielding or grounding failure is indicated if 50/60Hz spikes are seen.



3. Put Power Isolation and Filtering (System-Level Protection) into Practice

Add AC Isolation Transformer: To stop the common-mode conduction line, set up a different isolation transformer for the hot runner temperature control cabinet.

Use DC-DC Isolation Module: To prevent common-mode current, install an isolated DC-DC converter at the temperature control module's front end.

Install EMI Power Filter: To reduce high-frequency noise, install a filter at the main power inlet.

Independent Power Supply Circuit: Steer clear of connecting high-power devices (such an injection molding machine's main motor) to the same phase line.

Safety Principle: "High CMRR module + shielded wiring + power isolation" triple protection is essential.



4. Consistent Upkeep and Performance Evaluation

Every quarter, check the wiring terminals for oxidation and tightness.

Look for high-frequency spikes at the thermocouple input terminals using an oscilloscope.

Hire a third party to do official CMRR testing and certification following equipment overhauls or temperature controller replacements.

Create a temperature control stability file to document interference incidents and corrective actions. Value proposition: A single accurate anti-interference rectification can stop a batch of products from being scrapped because of temperature variations (a single loss often exceeds 10,000 yuan).
