Wireless Temperature Transmitter 4-20 MA Thermocouple/potentiometer/PT100 Temperature Converter And Temperature Transmitter

Overview SMT4001 series temperature transmitter uses high-resolution, high-precision temperature sensor probe as the measuring element,amplifier circuit is located in the stainless steel shell, to the convert a temperature signal to a standard electrical signal output. The product is widely used...

Send Inquiry

Description

Overview
SMT4001 series temperature transmitter uses high-resolution, high-precision temperature sensor probe as the measuring element,amplifier circuit is located in the stainless steel shell, to the convert a temperature signal to a standard electrical signal output.
The product is widely used in the field of petroleum, chemical, metallurgy, electric power, hydrology and other industrial temperature measurement owe to its excellent reliability, flexibility and diversity.

Feature

* Temperature measurement resolution: 1 ℃
* Temperature measurement range：-50℃~200℃
* Real-time temperature display
* High stability and high reliability

Measuring range	-50℃~200℃
Power supply	12V~30V DC
Signal output	4 mA～20mA DC
Load Resistance	≤（U-12）/0.02Ω
Protection class	IP65
Accuracy	±0.5％FS
Ambient temperature	-40℃～100℃（with display：-20℃～70℃）

SMT4001	Universal digital temperature transmitter
	Range			Measuring range
	［0～X］℃ X: Actual temperature			-50℃~200℃
		Code		Signal output
		E		4mA~20mA DC
			Code	Protection tube diameter, unit: mm
			6	φ6
			8	φ8
			12	φ12
				Code	Threaded interface
				C3	G1/2 male
				C5	M20*1.5 male
					Code	Probe length unit：mm
					1	150
					2	300
SMT4001-［0～100］℃ - E – 6 - C5 -1 the whole spec
