Application of Composite Curing Heating Pad Silicone Electric Heating Plate

Designed with silicone rubber composite bonding and curing heating pad for:
Reduction or elimination of super strong strain
Uniform heat distribution to produce optimal curing or bonding conditions
The composite curing heating pad silicone electric heating pad optimizes temperature uniformity through computer-designed resistance elements to achieve uniform heating. For larger heating pads, the circuit spacing should be maintained at 1/4 ", and for smaller heaters, the circuit spacing should be maintained at 1/4". This technology can ensure a temperature uniformity of ± 10 ° F (± 5.5 ° C) throughout the composite curing heating pad.
Composite curing heating pad leads pass through unheated 2 ″ × The 2 ″ lead outlet connector leaves the heater. This allows the silicone electric heating element to heat the entire heater surface while maintaining a separate unheated portion for transition from the resistor element to the lead and solid strain relief.
Application parameters of composite curing heating pad:
maximum temperature:
500 ° F/260 ° C intermittent
392 ° F/200 ° C continuous
Maximum width: 36 inches (914 millimeters)
Maximum length: 120 inches (3048 mm)
Maximum diameter: 32 ″ (813mm) T UL approved
Available voltage: 120 Vac or 240 Vac
Leader:
Teflon ®
Length 5 feet
400°F/200°C
600V
Characteristics of composite curing heating pad:
Material: Glass fiber reinforced silicone rubber
Smooth bottom layer in contact with cured composite materials
External lead outlet label (2 ″ × 2 ″) Maximize heating area and uniformity
The composite industrial watt density standard is 5 W/inch2
Meets the composite material industry uniformity standard of ± 10 ° F
Each heating pad can have a serial number that can be traced back to its source
Heat map certification available
Acceptable customization
